RG 200
tipping bucket rain gauge
with built-in tipping bucket system and additionally
recording on drum or strip chart, The wrifing device
is directly activated from the tipping bucket, and records
each impulsion. After 100 impulsions (10mm rainfall)
the pen is removed automatically to the zero-line.The
recording looks identical to the syphon type.
With the tipping bucket system, data loggers or transmission
systems can be connected directly. The tipping bucket
is fixed on one side with double ball bearings and can
be removed easily for cleaning.By its special form highly
accurate measurements are done. The complete tipping
bucket system can be adjusted separately (independent
of housing) to the horizontal position.
Technical details
| |
RG
200
rain gauge
|
RGB
200
drum recorder
|
RGB
200
strip chart
recorder
|
|
|
|
collecting
area
|
200㎠ |
200㎠ |
200㎠ |
|
|
|
recording
time
|
depending
on
type of
data loggr |
1
or 7 days
(indicate on
order) |
16
- 66 days (dependent on
paper and speed) |
|
|
|
clockwork
|
-
|
mechanical
or quartz
|
quartz
(paper
speed selectable
10/20 mm/h) |
|
|
|
power
supply
|
|
|
|
|
|
|
for
quartz clock
|
-
|
3V
(2×1.5V C size) |
6V
(4×1.5V C size) |
|
|
|
output
|
potential
free
contact |
potential
free
contact |
potential
free
contact |
|
|
|
resolution
|
1
impulsion
=0.1mm |
1
impulsion
=0.1mm |
1
impulsion
=0.1mm |
|
|
|
recording
height
|
-
|
80mm
= 10mm
rainfall |
80mm
= 10mm
rainfall |
|
|
|
collecting
bottle
|
5
I plastic |
5
I plastic |
5
I plastic |
|
|
|
measuring
vessel
|
(DIN
58667)plastic, 200㎠=10mm Niederschlag
|
|
|
|
dimensions
|
(height,
 housing,
roof)
1200mm×308mm×430mm
|
|
|
|
weight
|
approx.
17㎏ |
approx.
19㎏ |
approx.
19㎏ |
|
|
|
